Digital IC Dream Color 5050 RGBW 5in1LED Strips

Basic Info

Model NO.	Digital RGBWW strip
Beam Angle	120degree
SMD	5050(5chip in 1 LED)
CRI	Ra >80
Working Hour	50000hours
Warranty	3years
LED Brand	Refond
IC	TM1914 IC (8PCS)
Grey	256
Pixel	8 Pixel
Transport Package	Reel to Antistatic Bag, Then in Paper Box
Specification	5meter per reel, 10meter per reel
Trademark	Easing Home
Origin	China
HS Code	9405409000
Production Capacity	10000meter Per Day

Product Description

EasingHome innovative RGB+W+WW (RGB+CCT) (Red+Green+Blue+White+Warm-white) 5in1 flexible LED strips is new designed and have the great advantage of good color mixing performance and very strong flexibility. 5050 SMD RGBWW can replace 5050 RGB,RGBW and CTT adjustable led strip light.Through the RGBWW Remote controller programming to achieve any of Flashing effects.The smart digital RGB+W+WW strip working with TM1914 IC, it can work continously even one LED broken. it will give you very beautiful color mixing with DMX controller.Size:

updating ...



Technical Data:

Basi Parameter:
LED Qty	48LED per meter
SMD Type	5050 ( 5 chips in 1 LED)
PCB Width	12mm
PCB Material	2Ounce FPC
PCB Color:	white, Black, Brown
Warranty	3years
Specification Parameters
Luminous Flux(lm)	RGB: 360-385lm WW+PW: 595-625lm RGB+WW: 620-645lm RGB+PW: 685-715lm RGB+WW+PW: 930-965lm
Input Voltage	DC2V
CRI	Ra >80
Color	Red+ Blue + Green+ white + warm white ( 5chips in 1)
Power	8.4W per meter
Current/LED	70mA
Beam angle	120degree
Working temperature	-20ºC~+45ºC
Minim cuttable length	125mm (6LEDs 12V)
Acceessories
End cap, mounting clips, 300P 3M tape



Accessories:Adviced Aluminum Channel:
Any aluminum profile that suitable for 12mm PCB LED strip. we have over 300 types LED profiles. if youhave special request, pls contact us for more details on our profile catalogues. thanks.

Package:Application:

• City skyline lighting villas advertising wall signs Christmas ( , , decorative landscape)
• Irregular design of body decoration (shopping malls, hotels, nightclubs, polygonal wall KTV
• establishments ceiling cavity design)
• Public lighting lighting (schools, libraries, hospitals, airports, subway stations, railway stations)
• Furniture dark groove trim (door, bar, wine cabinet, wardrobe, TV cabinets, etc.)
• Automotive beauty (body, underbody, wheelbarrow balanced car, etc.)

What's difference between RGBW and RGBWW Led strip ?RGBW 4in 1 LED, RGBWW 5in 1LED

RGBW VS RGBWW

RGBW LED strip has been around for a while now and has opened the door to previously unheard-of lighting possibilities, allowing not only a wide range of customisable colors but also the ability to cut and join any length to create totally unique shapes. In response to popular demand though, there's now a new kid on the block, RGB+CCT, which adds an extra white chip into the mix. Why might you need this? Read on..

What's the difference between RGBW and RGBWW LED strip?

Standard RGBW LED strip use a 4-in-1 LED chip made up of red, green,blue and W chips. It can produce a wide range of colors by mixing the four and looks almost white with all at full brightness. RGB+W+W LED strip uses either a 5-in-1 LED chip that has A Warm white chip and RGB Led, also has a White color on the right.

Why would you want an extra Warm White and white chip?

Although RGB and RGBW can produce a colour close to white, a dedicated white LED provides a much purer white tone and allows you the option of an extra warm or cool white chip. The extra white chip also provides extra scope for colour mixing with the RGB chips to create a huge range of unique shades.The RGB+Warm white and white color. They are adjustable. You can control bright of warm white and white. Really suitable for bed room and KTV, so it is welcome.

Which is better?

The better choice is really down to the application. If all you're after are basic RGB colours with no requirement for pure white then basic RGB LED strip is generally more cost effective and efficient. However for those looking for the option of white and RGB colours, as well as a mix of both, then RGB+W is a better bet. But is you want to get the different bright of white color. The RGB+Warm white +white will be a great choice. Also has a special RGB+WW+W controller.

This RGB+Warm white +White controller is just for RGB+Warm White+White. Not connect other RGB and RGBW led strip.

Are the controllers different?

Yes. RGB+W lighting controllers have five outputs, one for each colour and one for power. As RGB has one less chip, it only requires four. The functionality of the control also has to be different to control the white part of the LED in RGB+W. The RGB+Warm white+White will have own controller. This is only one controller,you can choose what color you want.
