Indoor Thermostat Display LCD Display, LCD Panel, LCD Module Touch Screen Transparent Display, LCD Monitor, Cog LCD Display, Custom Screen Monochrome Screen

Basic Info

Model NO.	YX-TN56DS26134
Screen Size	53(W) X 47(H)X2.8(D)
Application	Indoor, Advertising, Outdoor, Surveillance, Instrument and Meter
Type	TN
Response Time	10ms
Interface Type	Metal Pin
Display Type	Positive Transmissive
Viewing Direction	12 O′clock
Module Size	53(W) X 47(H)X2.8(D)
Active Area	50(W) X 40(H)
Drive Method	1/4duty, 1/3bias
Operating Voltage	5.0V
Connector Type	Metal Pin
Operating Temperature	-20~70
Storage Temperature	-30~80
Transport Package	Carton
Trademark	YX
Origin	Shenzhen
Production Capacity	80000PCS/Day

Product Description

Why you choose us?

1. We are manufacturing Full Range of Mono & TFT LCD Display.2. We can custom TN LCD, HTN LCD, STN LCD, FSTN LCD, DFSTN LCD, COG LCD, and some other small size OLED.3. We have developed thousands of LCD and LCM products for telecom, consumer electronics, medical equipment industrial equipment and other applications.4. No middleman, you can get button price from a professional factory.5. Excellent after-sales services and long warranty ensure you no more worries.

Product Description

Product Parameters

NO.	Item	Specification	Unit
1	LCD Type	TN	-
2	Display Type	Positive Transmissive	-
3	Viewing Direction	12 O'CLOCK	-
4	Module Size	53(W) X 47(H)X2.8(D)	mm
5	Active Area	50(W) x 40(H)	mm
6	Drive method	1/4duty, 1/3bias	-
7	Operating voltage	5.0	V
8	Driver IC	/	-
9	Connector Type	Metal pin	-
10	Operating Temperature	-20~70	ºC
11	Storage Temperature	-30~80	ºC

Application scenarios

LCD Type: TN, HTN, STN, FSTN, VA, COB, COG customized according to your requirements

Display content: Any digitals, icons, graphic can be customized and designed according to your requirement

Polarizer type: Transmissive, Transflective, Reflective

Operating voltage: 2.8v,3.0v,3.3v,4.5v,5.0v according to your requirements

Connector Type: FPC, Metal Pins, Zebra, Heat-seal

Glass thickness: 1.1mm, 0.7mm, 0.55mm,0.4mm

Various Backlight color available

Various Temperature range available:0ºC~50ºC/-10ºC~60ºC/-20ºC~70ºC /-30ºC~85ºC

Viewing angle: 3o'clock,6 o'clock ,9 o'clock,12 o'clock

Company ProfileYu Xiang has been established for 10 years and has always believed in humanistic care. It has built a stable and excellent work team to provide customers with satisfactory services.

Customer feedbackPackaging & Shipping
FAQ

Q: Are you a manufactory or trade company?
A. We are a professional manufacturer, which specializes in TN, HTN, STN, FSTN, VA/BTN monochrome LCD, Micro OLED Screen, Color TFT Display Panels, LED Backlights, LCD Modules located in Shenzhen and Jiangxi.

Q: How can I get the samples?
A: Your send sketch or pictures or tell us your idea → We offer quotation →You confirm quotation & pay tooling charge → We provide formal drawing → You confirm drawing → We make a tooling & samples → Delivery to you.

Q: How long can I expect to get the sample?
A: Design drawing: 2-3 days Sample time: 10-15 business days.

Q: Can you design the LCD in accordance with our demand?
A: Sure. We are professional custom factory. we provide all kinds of LCD and LCM according to customers' various requests, can also provide touch function on the screen. And we will give you the best tooling charge to support development in the initial stage.

Q: How to place orders?
A: Samples are OK for you → You send us purchase order →We send you Proforma Invoice →You pay deposit payment → We start toarrange production.

Q: Can I get a lower price of lcd display?
A: Yes, cheaper price with bigger/larger quantities order.

Q: What is the minimum order quantity?
A: All our products have MOQ requirements, please contact our salesman for detailed information.

Q: How long of mass production?
A: Usually 20-30 business days. It depends on different order quantities and part numbers.
